4D LCD 35480320 3.5" TFT Liquid Crystal Displays

4D LCD 35480320 3.5" TFT Liquid Crystal Displays are color active matrix LCD modules integrating an amorphous silicon thin-film transistor. The 35480320 Displays include a color TFT-LCD panel, driver IC, FPC, and a backlight unit. Options available include with or without a Resistive/Capacitive Touch Panel (RTP or CTP) and with or without Cover Lens Bezel (CLB). The 4D LCD 35480320 3.5" Displays offer a 320 x 480 resolution pixel area.

Features

LCD Type: TFT / Transmissive / Normally white
3.5# size"
The touch panel is available in non-touch, resistive touch, and capacitive touch
6:00 viewing direction
12:00 gray scale inversion direction
48.96mm × 73.44mm active area (WxH)
0.2025mm × 0.2025mm dot pitch (WxH)
320 x 480 display resolution pixels
MCU-16bit/SPI interface type
Surface luminance
- 4DLCD-35480320: 228cd/m² (typical)
- 4DLCD-35480320-RTP: 182cd/m² (typical)
- 4DLCD-35480320-CTP: 216cd/m² (typical)
- 4DLCD-35480320-CTP-CLB: 216cd/m² (typical)

262K color depth
HX8357D driver IC
6 LEDs backlight type
RGB vertical stripe pixel arrangement
AG surface treatment
2.8V (typical) input voltage
Module size - W x H x T
- 4DLCD-35480320: 54.50mm x 83.00mm x 2.10mm
- 4DLCD-35480320-RTP: 54.50mm x 83.00mm x3.35mm
- 4DLCD-35480320-CTP: 54.50mm x 83.00mm x 4.00mm
- 4DLCD-35480320-CTP-CLB: 123.04mm x 84.46mm x 4.62mm (including CLB)
-20°C to +70°C operating temperature range
RoHS compliant
