Analog Devices Inc. ADP7104x-EVALZ Evaluation Boards
Analog Devices Inc. ADP7104x-EVALZ Evaluation Boards are designed to evaluate ADP7104 Low Dropout (LDO) regulator. This regulator operates from 3.3V to 20V and provides up to 500mA of output current.
Schematic: SOIC Package OR SOIC Package Schematics
Schematic: LFCSP Package OR LFCSP Package Schematics
Associated Product
Analog Devices Inc. ADP7104 LDO Linear Regulators
20V, 500mA, Low Noise, CMOS LDO Regulators.
Published: 2020-06-24
| Updated: 2022-03-11
